Panasonic CM602 Pick and Place Machine
- weioght: 3 400 kg
- Max.speed 100 000 cph
- Application components:0402 (01005)
- PCB dimensions:L 510 x W 460
- Product description: Panasonic CM602 Pick and Place Machine, Mounting Speed: 100,000 CPH, Application components:0402 (01005), PCB dimensions:L 510 x W 460, weioght: 3 400 kg
Panasonic CM602 Pick and Place Machine
The Panasonic CM602 is a top-of-the-line printer that offers superior printing quality and speed. It prints at resolutions up to 1200 x 1200 dpi and can reach speeds of up to 60 ppm. The CM602 also has a variety of convenient features, including wireless connectivity, duplex printing, and an intuitive touch screen interface.
Why We Will Buy Panasonic CM602 Pick and Place Machine
Looking for a powerful and reliable pick-and-place machine? The Panasonic CM602 is just what you need. With its high-speed placement head and intelligent software, it can handle even the most challenging jobs with ease. Plus, it’s backed by Panasonic’s reputation for quality and reliability. So if you’re looking for a top-of-the-line pick-and-place machine, the Panasonic CM602 Pick and Place Machine is a perfect choice.
The Panasonic CM602 is a top-of-the-line digital camera that is perfect for anyone looking to take stunning photos and videos. It features a large sensor that allows you to capture beautiful images and videos in any lighting conditions, an impressive autofocus system, and a 4K video recording.
Features & Benefits:
One platform solution for any kind of production
Commonality with existing equipment
Linear motor drive increases reliability and reduces maintenance
Wide component capability from 0402 (01005) chips to 90 x 100mm on up to 18″ x 20″ boards
Panasonic’s CM602 high-speed multi-functional placement machine lets you achieve world-class throughput via the light head, high-speed recognition camera, and linear motor. Fully compatible with our successful CM series feeder units, nozzles, and operation, this single platform solution can place up to 100,000 components per hour by selecting the best-suited combination of high-speed and multi-functional heads. Fast, flexible, and intelligent – the CM602 takes your productivity to new heights.
|PCB dimensions (mm)||L 50 x W 50 to L 510 x W 460|
|High-speed head||12 nozzles|
|Max. speed||100 000 kph (0.036 s/chip)|
|Placement accuracy||±40 µm/chip (Cpk1)|
|Component dimensions (mm)||(01005″) 0402 chip *5 to L 12 mm × W 12 mm × T 6.5 mm|
|High-flexibility head||LS 8 nozzles|
|Max. speed||75 000 kph (0.048 s/chip)|
|Placement accuracy||±40 µm/chip, ±35 µm/QFP 24 mm,|
|±50 µm/QFP <24 mm (Cpk1)|
|Component dimensions (mm)||(01005”) 0402 chip *5 to L 32 mm × W 32 mm × T 8.5 mm *8|
|When the generalized Ver.5 is optionally selected (01005”)0402 chip *5 to L 100 mm × W 50 mm × T 15 mm *6|
|Multi-functional head||3 nozzles|
|Max. speed||20 000 kph (0.18 s/QFP)|
|Placement accuracy||±35 µm/QFP (Cpk1)|
|PCB exchange time||0.9 s (Board length: up to 240 mm Under optimum conditions)|
|Electric source||3-phase AC 200, 220, 380, 400, 420, 480 V, 4.0 kVA|
|Pneumatic source *1||0.49 MPa, 170 L /min(A.N.R.)|
|Dimensions (mm)||W 2 350 x D 2 290 *2 x H 1 430 *3|
|Mass *4||3 400 kg|
BUYING USED EQUIPMENT FROM BUYSMT?
Buysmt’s technicians prepare each machine for
a fully functional demonstration.
We welcome our client’s acceptance criteria,
even application based.
We encourage all of our clients to visit for a complete demonstration of the machine’s functionality,
but we can also provide a demonstration by video for your review.
We will also try to accommodate any special acceptance criteria that you may have.
Our goal is to eliminate your buyer’s risk…
WHAT’S THE PURCHASE PROCESS TYPICALLY LIKE?
When a client decides that they would like to pursue a machine,
they will issue a conditional purchase order.
Buysmt will then place the machine on hold and schedule a demonstration for their approval.
The demonstration is either conducted at our facility or by video. If the client accepts the machine,
Buysmt will then invoice against this purchase order. The machine will be prepared by vigor technicians for shipment.
Buysmt will load the machine onto the buyer’s truck. If there are special packing needs,
Buyer will be happy to help with all the arrangements.
Buysmt can provide ocean packing when needed.
SHOULD I BE BUYING USED EQUIPMENT?
Used equipment is a very popular choice for many manufacturers worldwide.
Even the largest manufacturers consider used equipment for their needs; however,
Buysmt feels that it is not always the best solution for a client.
Buysmt makes available each piece of equipment for fully functional demonstration,
which substantially reduces are buyers’ risk. With many used equipment suppliers and auctions,
the equipment is not available for functional demonstration.
Only very experienced buyers should participate in this type of purchase unless you have incorporated this risk into your purchase price.
DOES BUYSMT OFFER A WARRANTY WITH THE EQUIPMENT?
Buysmt is all about reducing your purchase risk.
We will bend over backward to make sure that you have every assurance of the equipment’s condition prior to purchase,
but we do not offer a warranty on the equipment.
CEE is responsible for supplying all the information you need to make an informed purchase decision on the equipment.
We can not be responsible for the machine after it leaves our facility.
Why? Our goal is to supply used equipment that is fully functional and ready for production.
We are not here to replace the OEM, which has a much lower cost on their spare parts.
If a warranty is a must for you, please discuss it with your vigor sales agent.
We do have extended protection options for buyers who require it.
HOW DO I SELL MY USED TO EQUIPMENT TO BUYSMT?
The process is simple. Call VIGOR! VIGPR will review your equipment list.
We will supply you with a simple question list on the equipment.
When we receive your answers, we will supply you with an offer conditional upon inspection.
If you accept the offer, Buysmt will have a technician inspect the equipment within a couple of days. I
f it’s good equipment, Buysmt will issue a purchase order for the equipment and send the money.
We will make all the arrangements for pick-up. It’s that easy.
